DZ2 Dev Board & Kit with AMD Zynq™ 7000 SoC XC7Z020
Brand: Alinx
EIC Product Code: DZ2
ALINX DZ2 – Zynq‑7000 SoC board with 1GB DDR3, GbE, HDMI, MIPI, CAN/RS485, and FMC. Ideal for industrial control, video, and edge computing.
Product Description
The DZ2 development board features the AMD/Xilinx Zynq™ 7000 SoC (XC7Z020), integrating a dual-core ARM Cortex™-A9 processing system with Artix-7 FPGA fabric. Equipped with 1GB DDR3 SDRAM, 32MB QSPI Flash, Gigabit Ethernet, dual CAN/RS485, HDMI Output, MIPI CSI-2 camera input, and a standard FMC LPC expansion connector, the DZ2 delivers a high-performance, flexible solution for industrial control, video processing, and edge computing applications.
Applications
Automotive
● Road Sign Recognition
● ADAS
● Smart Transportation
Communication Network
● Ethernet Backhaul
● Small Cell Baseband
● Network Switch
● Flexible radio platform
Industrial
● Motor control
● Industrial Control
● Industrial IoT
● Instrumentation
● Smart Grid
Video and Image Processing
● Professional Cameras
● Computer Vision
● Machine Vision
Medical
● Endoscop
● Ultrasound, CT, MRI
Key Features
System-on-Module（AC7Z020）
● AMD/Xilinx Zynq™ 7000 SoC XC7Z020 :
◆ ARM® dual-core Cortex™-A9
◆ Artix 7 28nm FPGA fabric
◆ 85K Logic Cells, 220 DSP Slices● Pluggable module with2x Panasonic board-to-board connectors
● 1 GByte (32-bit) DDR3 SDRAM on PS
● 32 MB QSPI Flash
● Pluggable module with 2x Panasonic board-to-board connectors
● Module dimensions: 42 x 35 mmBase Board
● 1 x HDMI Output (1080P@60Hz)
● 1 x MIPI CSI-2 Camera Input
● 1 x Gigabit Ethernet
● 1 x FMC LPC (34 diff pairs + 2 clocks)
● 2 x CAN interface
● 2 x RS485 interface
● 1 x USB 2.0 OTG (Type-C)
● 1 x USB-to-UART (Type-C)
● 1 x JTAG
● 4 x AD
● 1 x Micro SD
● 1 x EEPROM 24LC04 (4Kbit, I2C)
● 1 x RTC DS1338(Real-time Clock)
● 1 x Temperature sensor LM75
● 1 x User Button
● 2 x User LEDs
● 12V DC power input (USB Type-C)
● Dimensions: 155 x 90 mm form factor
Development Board Features
Featuring the AMD/Xilinx's Zynq™ 7000 SoC XC7Z020-2CLG400I Adaptive SoC
Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any AMD/Xilinx Zynq™ 7000 SoC based application.
* The DZ2 development board consists of a AC7Z020 SoM and base board. If you want to purchase AC7Z020 SoM separately.
Please check the Relevant Products at the bottom of the page and click to learn more details.
What's Inside the Box
ALINX AMD Xilinx Zynq™ 7000 SoC XC7Z020 development board and Some accessories
| System-on-Module | 1 | Base Board | 1 |
|---|---|---|---|
| USB Type‑C cable | 2 | USB Downloader Cable / set | 1 |
| 12V Power Adapter | 1 | Acrylic board | 1 |
| TF Card | 1 | Card Reader | 1 |
Product Matrix
1. For non-preferred models, a minimum order quantity (MOQ) may apply if the products are not in stock.
2. We offer custom configuration, a MOQ applies.
Please contact us for more details.
We offer complete documentations and a lot of demos and tutorials.
Please contact us should you have any need.
