AXVP1502P Dev Board & Kit with AMD Versal Premium XCVP1502
EIC Product Code: AXVP1502P
Product Description
The AXVP1502P is a professional-grade development board powered by the AMD Versal™ Premium XCVP1502-3HSEVSVA2785 FPGA. Designed for high-speed data exchange, storage, video transmission, deep learning, and AI acceleration, this board delivers exceptional performance for demanding applications in data centers, industrial automation, and advanced communications.
Featuring two DDR4 SODIMM slots (up to 32 GB total), 32 GB eMMC Flash, 256 MB QSPI Flash, and a rich set of high‑speed interfaces — including PCIe Gen5/4 x16, four 400G QSFP‑DD optical ports, two FMC+ expansion connectors, M.2 (PCIe Gen3 x4), Gigabit Ethernet, USB 2.0 Host, and UART — the AXVP1502P provides a versatile and scalable solution for system prototyping and validation. With 60 GTM transceivers, 28 GTYP channels, and ample logic resources, it is ideally suited for AI inference, real‑time signal processing, and high‑throughput data acquisition.
Applications
High‑Speed Data & Networking
● 400G optical transport and switching
● PCIe Gen5/4 acceleration cards
● Data center storage and compute offload
AI & Machine Learning
● Deep learning inference acceleration
● Real‑time image and video analytics
● Sensor fusion for autonomous systems
Industrial & Automation
● Predictive maintenance and condition monitoring
● High‑precision motion control
● Edge computing for factory automation
Test & Measurement
● High‑speed data acquisition systems
● Radar and LIDAR signal processing
● Software‑defined radio (SDR) platforms
Key Features
- ● AMD Versal™ Premium XCVP1502:
◆ 3.76M Logic Cells
◆ 60 GTM and 28 GTYP transceivers
● 256 MB QSPI Flash
● 32 GB eMMC Flash
● 2 x DDR4 SODIMM slots (up to 32 GB, 72‑bit wide, 2666 Mbps)
● PCIe x16 (Gen5.0 x8 or Gen4.0 x16)
● 4 x QSFP‑DD ports (up to 400 Gb/s each)
● 1 x M.2 Key‑M - ● 2 x FMC+ HPC connectors◆ FMC1: 24 GTM
◆ FMC2: 8 GTYP
● 1 x Gigabit Ethernet
● 1 x USB 2.0 Host (Type‑A)
● 1 x USB‑UART
● 1 x Micro SD card slot
● 5 x IPEX connectors (clocks, triggers)
● 1 x JTAG
● 12V single supply
● Dimensions: 256mmx 106.6mm form factor
Development Board Features
Featuring the AMD Versal Premium XCVP1502-3HSEVSVA2785 Adaptive SoC
Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any AMD Versal AI Edge based application.
What's Inside the Box
ALINX AMD Versal Premium SoC development board
| Development Board | 1 | Heatsink Kit (preinstalled) | 1 |
|---|---|---|---|
| 16GB DDR4 memory module | 2 | 512G SSD | 1 |
| SD card (with system) | 1 | PCle Fence | 1 |
| 12V power supply and adapter | 1 | Downloader | 1 |
Product Matrix
| Product Model | Preferred Model | Versal AI Edge | QSPI Flash | eMMC Flash | GTM | GTYP | USD Price | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AXVP1502P | √ | XCVP1502-3HSEVSVA2785 | 256 MB | 32 GB | 60 | 28 | 17971 |
1. For non-preferred models, a minimum order quantity (MOQ) may apply if the products are not in stock.
2. We offer custom configuration, a MOQ applies.
Please contact us for more details.
We offer complete documentations and a lot of demos and tutorials.
Please contact us should you have any need.
