AXK101 FPGA Dev Board & Kit with Pango Kosmo-2 PG2K100
Brand: Alinx
EIC Product Code: AXK101
AXK101 is a Kosmo-2 FPGA platform powered by the PG2K100-6IMBG484 SoPC (dual-core ARM Cortex-A53 + FPGA), with 2GB DDR4, 8GB eMMC, 16MB QSPI Flash, 5x Gigabit Ethernet, 4x USB 2.0 Host, HDMI, USB-UART, SD, JTAG and 40-pin expansion ports.
Product Description
AXK101 is a professional Kosmo-2 FPGA development platform based on the PG2K100 SoPC, which integrates a dual-core ARM Cortex-A53 processor and FPGA logic on a single chip. It features a core board with PG2K100, 2GB DDR4 SDRAM, 8GB eMMC, and 16MB QSPI Flash, and a base board that provides 5x Gigabit Ethernet, 4x USB 2.0 Host, HDMI, USB-to-UART, SD card, JTAG, and 40-pin expansion ports for high-speed data exchange, video processing, and industrial applications.
Applications
Automotive
● Road Sign Recognition
● ADAS
Communication Network
● Ethernet Backhaul
● Small Cell Baseband
● Network Switch
● Software Defined Radio
Industrial
● Motor control
● Industrial Control
● Industrial IoT
● Instrumentation
● Smart Grid
Video and Image Processing
● Professional Cameras
● Computer Vision
● Machine Vision
● Video Surveillance
Medical
● Endoscopy
● Ultrasound, CT, MRI
Key Features
System-on-Module
● PANGOMICRO Kosmo-2 SoPC:
◆ ARM® dual-core Cortex™-A53 up● Pluggable module with 4 x board-to-board connectors
● 2 GB (32-bit) DDR4 SDRAM on PU
● 16 MB QSPI Flash
● 8 GB eMMC Flash
● 1 x UART to USBBase Board
● 5 x Gigabit Ethernet (1 x PU, 4 x PA)
● 1 x HDMI
● 4 x USB2.0 Host
● 1 x UART to USB
● 1 x USB JTAG
● 2 x 40-pin Expansion Port
● 1 x Micro SD
● 3 x LED (1 power, 2 user)
● 2 x user keys
● 12V single supply
● Dimensions: 150 x 110 mm form factor
Development Board Features
Featuring the PANGOMICRO Kosmo-2 SoPC PG2K100-6IMBG400 Adaptive SoPC
Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any PANGOMICRO Kosmo-2 SoPC based application.
* The AXK101 development board consists of a K101 SoM and base board. If you want to purchase K101 SoM separately.
Please check the Relevant Products at the bottom of the page and click to learn more details.
What's Inside the Box
ALINX Kosmo-2 SoPC PG2K100 development board and Some Accessories
| Base Board | 1 | System-on-Module | 1 |
|---|---|---|---|
| Mini USB Cable | 2 | USB Downloader Cable / set | 1 |
| 12V Power Adapter | 1 | Acrylic board | 1 |
| TF Card | 1 | Card Reader | 1 |
Product Matrix
| Product Model | Preferred Model | FPGA Devices | DDR4 SDRAM | QSPI Flash | eMMC Flash | USD Price | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AXK101 | √ | PG2K100-6IMBG400 | 2 GB | 16 MB | 8GB | / |
1. For non-preferred models, a minimum order quantity (MOQ) may apply if the products are not in stock.
2. We offer custom configuration, a MOQ applies.
Please contact us for more details.
We offer complete documentations and a lot of demos and tutorials.
Please contact us should you have any need.
