Handle Controller
EIC Product Code:
Re-programmable output characteristics | Isolated RS422 | Isolated CAN | USB | Configurable button structure (up to 32 inputs) | SPI potentiometer support (2 ports)
SERIAL INTERFACES
- Isolated RS422
- Isolated CAN
- USB
INPUT OPTIONS
- Configurable button structure (up to 32 inputs)
- SPI potentiometer support (2 ports)
- Analog potentiometer support (2 ports)
- Hardwired switch support
- Re-programmable output characteristics
OUTPUT CHARACTERISTIC
- Individual programmable output characteristic
- Up to five polynomial functions are storable
- Output characteristics can be selected during operation via the data link
Availability: in stock
Supply Voltage: 9-36 V DC according to MIL-STD-1275
Interfaces: 1x RS422 up to 115200bps / 2x CAN up to 1MHz / 1x JTAG Programming Interface / 1x USB Interface
EMI/EMC Protection: According to MIL-STD-461 ground vehicles
Environmental Conditions: According to MIL-STD-810 ground mobile
Temperature Range: – 40° C to + 70° C operation, – 51°C to + 71° C storage
ESD Protection: According to ICE 61000-4-2
Dead Zone: Output signal, 5+/– 3 % Mechanical dead band, Electrical adjustable due to polynomial output function
