JESD204B IP Core

EIC Product Code:

Logic Fruit Technologies has designed JESD204B RTL IP. It can support increased lane rates upto 12.5Gbps for higher bandwidth applications. It can be configured to transmit or receive using a 8B10B link layer to achieve deterministic latency, SerDes synchronization, clock recovery and DC balance.

Availability: in stock
  • Applicable in RADAR, Medical Imaging as it supports higher bandwidth and more number of channels with fewer pins to simplify layout.
  • Applicable in Wireless Communications, TDMA & OFDM based technologies such as LTE, WiMAX can benefit from high frequency scalability provided by JESD204B.
  • JESD204B is necessary for high density systems as it provides reduced PCB area and package size.
  • Comparable power for large throughput.
  • Provides interface for serializing devices from some system designs, reducing space, power, and cost.
  • Mechanism to achieve Deterministic latency across the serial link.

  • RTL Source Code or Encrypted Netlist

  • Testbench and Simulation Environment

  • Integration Support & Documentation
