Image Overview

ARINC818 IP Core

EIC Product Code:

The Logic Fruit ARINC 818 IP Core enables high-speed, low-latency video and data transmission for aerospace applications. It supports ARINC 818-2/3 standards with data rates up to 28 Gbps and resolutions up to 4K. Designed for FPGA implementation, it offers reliable performance and easy integration into avionic systems.

Availability: in stock
  • Compliant to ARINC818-2 and ARINC818-3 Specification. The max speed supported is 12.75 Gbps and 28 Gbps.
  • Built on Fiber Channel Audio Video protocol.
  • Point-to-Point Video/Data Transmission support using 8B/10B, 64B/66B and 256B/257B Encoding over the serial link.
  • Supports both optical and electrical links.
  • Supports line-segmentation and line-synchronous transmission.
  • Receiver error and status reporting with support for user data.
  • CEMILAC certified and DO-254 DAL-B Compliant design.

  • Synthesizable RTL code (VHDL/Verilog)

  • Testbenches and simulation files

  • Integration guide and user manual

  • Optional customization and support packages

Documentations
