Display Port IPs

EIC Product Code:

DISPLAY PORT Transmitter & Receiver IP Cores supports multiple line rates up to 8.1Gbps. The IP cores have been developed as per Display Port specifications DP2.0/eDP1.5.

Availability: in stock

DISPLAY PORT Transmitter and Receiver IP Cores are adhering to Display Port 2.0/eDP1.5 standards. These cores support line rates up to 8.1 Gbps and offer flexible features like multi-stream transport for up to 4 streams, dynamic lane support, HDR metadata, and audio output for 2 to 8 channels, ensuring superior multimedia performance.

  • Compliant to Display Port 2.0/eDP1.5.
  • Dynamic support for RGB / YCbCr444 / YCbCr422 / RAW and Y only formats.
  • Supports multi-stream transport (MST) upto 4 streams and single stream transport (SST).
  • Dynamic lane support (1, 2, or 4 lanes).
  • Dynamic link rate support (1.62/2.7/5.4/8.1 Gb/s).
  • Dynamic support for variable bpc.
  • HDR Metadata support on secondary stream.
  • Supports 2 to 8 channels Audio outputs.
